Battery capacity: (B2-10.24 kWh) (B3-15.36 kWh) (B4-20.48 kWh) (B5-25.6 kWh) (B6-30.72 kWh)
Nominal voltage: 51.2 V
Recommeded Charge/Discharge Current: (B2-100 A) (B3-150 A) (B4-200 A) (B5-250 A) (B6-300 A)
Maximum Charge/Discharge Current: (B2-100 A) (B3-150 A) (B4-200 A) (B5-250 A) (B6-300 A)
Charging Temperature: 0° – 50°C
Discharge temperature: -10°-50°C
Warranty Cabinet: 3 years
Warranty Battery: 10 years
Empty Weight: 68kg
Weight: (B2-120 kg) (B3-170 kg) (B4-220 kg) (B5-270 kg) (B6-320 kg)
Dimensions: W720 mm x D400 mm x H1150 mm
Enclosure Protection: IP20 (indoor)
Altitude: < 4000 m
Structure: SGCC(Galvanized steel),Busbar integrated, Floor mount
Cooling: Natural Convection
